UTG OP3 MICRO, RED 4.0 MOA DOT, ADAPTIVE BASE OP-RMR20R
DETAILS
- Precision Machined from 6061-T6 Aluminum and Finished in a Matte Black Anodization
- Red 4.0 MOA Single Dot with 8 Brightness Intensity Settings
- 55,000+ Hours Battery Life at Middle Brightness Setting
- Magnetized Battery Compartment Reduces Intermittent Reticle Illumination and Flicker
- Crisp 1 MOA per Click Adjustment
- Large FOV Multi-coated Glass Lens
- IPX7 Waterproof Rated
- Includes Removable Low Profile Picatinny Mounting Base
- Mounting Base Interface Uses the Common RMR® Footprint
- Optic Height Co-witnesses with Most Suppressor Height Iron Sights
- Tertiary Aiming Point Laser Engraved on Rear Face of Optic Hood
- Protective Optic Cover Included
- Compatible with Most Optics Ready Pistol Systems
CAUTION:Â Only use the included #6-32 or #4-40 screws for optic installation.
NOTE:Â We recommend tightening the #6-32 or #4-40 screws with torque value of about 12 inch-lb and the side plate screw with torque value of about 35 inch-lb.
SINGLE DOT RETICLE
Target Dot reticle consists of a single floating dot in the center as the aiming point with the least visual distraction. It is commonly used for quick aiming applications with lower demand for pin-point accuracy. The shooter aims by pointing the dot at the target. For a reflex dot sight based on light reflection, the sight usually does not have magnification and there is an unlimited eye relief. The dot is a reflected image of the light source with common characteristics from any light reflection, including possibly slight flare and fuzziness of the dot.
INNOVATIVE TRUE STRENGTH TS PLATFORM
HISTORY, DEVELOPMENT, & TECHNOLOGY
TS, as in True Strength®, is the signature scope construction platform of Leapers UTG® optics. As the name suggests, no matter if it's a full size or compact scope, magnifier or dot sight, we aim to achieve the highest dependability starting at the heart of our scopes' structure. The research and development of this innovative structure was initiated in 2001 and in 2002 the first TS Platform scope was put into mass production. With our continuous testing, verification, and multiple rounds of improvement, we started promoting and selling TS optics on a global scale in 2005. Today, all our optics are built on the tough TS Platform to include a one-piece integral aluminum main tube, meticulously placed reinforcements at key structural points, and nitrogen purging to achieve optimal rainproof, fogproof, and shockproof performance even in the most challenging of scenarios. This superior TS Platform has even been adopted into the lineup of UTG® laser products, giving them precise and secure adjustment.
Â
SMART SPHERICAL STRUCTURE
- The Smart Spherical Structure (SSS) is one of the most significant characteristics of the TS Platform.
- SSS simulates the human joint structure to achieve the utmost precision and reliability.
- The erector tube is constrained via a ball and socket structural relationship, which provides the desirable flexibility to respond to windage and elevation adjustments and the optimal ability to hold zero under heavy recoil.
TRUE STRENGTH® PLATFORM
- Reduces and Absorbs Recoil, Alleviating Potential Loss of Zero
- Fully Tested on Both Air Rifles and Firearms
- TS Technology Implemented in Every Leapers Scope
ADVANCED RECOIL PROOF SYSTEM
- The Most Advanced and User-friendly Windage and Elevation Adjustment System with Innovative Design, Precision Components, and Disciplined Assembly
- UTG®'s Leaf Spring System is Made from a Special Heat Treated Beryllium Bronze Alloy to Maintain Reliable and Consistent Long Term Tension
- ACCUSHOT® Models Equipped with a Rugged Coil Erector Return Spring System For Improved Zero Hold Under Heavy Recoil and Greater Windage/Elevation Adjustment Range
SPECIFICATIONS
| MADE IN USA | No |
|---|---|
| WARRANTY | Lifetime |
| MATERIALS | 6061-T6 Aluminum |
| COLOR(S) | Black |
| PARTS INCLUDED | #4-40 T10 Torx Screw, #6-32 T10 Torx Screw, Cleaning Cloth, CR2032 3V High Energy Lithium Battery, Dot Sight Owners Manual, Hex Wrench 3mm, Protective Optic Cover, T10 Torx Wrench, W/E Adjusting Wrench |
| WATERPROOF RATING | IPX7 |
| RETICLE | Single Dot |
| RETICLE COLOR(S) | Red |
| ILLUMINATION TOGGLE TYPE | Button |
| BRIGHTNESS MODE(S) | Manual |
| BATTERY TYPE | CR2032 3V |
| BATTERY LIFE (HRS) | 55000 |
| BATTERY LOADING | Bottom |
| CLICK VALUE @ 100 YARDS (MOA) | 1 |
| MAGNIFICATION | 1 |
| PARALLAX (YDS) | Infinity |
| PARALLAX (M) | Infinity |
| LENS MATERIAL | Glass |
| OPTIC FOOTPRINT | RMR |
| OPTIC TO MOUNT TORQUE VALUE (IN-LB) | 12 |
| MOUNT TO RAIL TORQUE VALUE (IN-LB) | 35 |
| WEIGHT (OZ) | 1.1 |
| WEIGHT (G) | 31.2 |
Â
DIMENSIONS
| HEIGHT (IN) | 1.02 |
|---|---|
| HEIGHT (MM) | 26.42 |
| LENGTH (IN) | 1.81 |
| LENGTH (MM) | 45.212 |
| WIDTH (IN) | 1.18 |
| WINDOW SIZE (IN) | 0.951575 |
| WINDOW SIZE (MM) | 24.17 |
Â
RESOURCES
LEAPERS LIFETIME WARRANTY
Â
Leapers, Inc. warrants that all products conform to published specifications and are free from defects in material and workmanship. Leapers, Inc. will repair or replace, at our discretion, a defective product for the duration of the product’s lifespan. Verification through an RA number is required. In the event of a product being discontinued, credit in the amount of the product’s MSRP may be offered.
